Grade 2 Titanium Socket Head Cap Screws

Commercially pure Grade 2 titanium socket head cap screws for compact, corrosion-resistant assemblies. Internal-hex geometry, thread, length, surface condition, mating parts and inspection follow the standard or drawing.

Material: Grade 2 / UNS R50400
Head & Drive: Cylindrical head / hex socket
Threads: Metric, UNC, UNF or drawing
Documents: MTC, dimensions and thread inspection

Product Detail

Product Introduction

Grade 2 socket head cap screws provide compact wrenching access with commercially pure titanium corrosion resistance. A complete order defines socket and head geometry, thread tolerance, length, Grade 2 condition, finish, mating material and acceptance requirements.

Product Specifications

Product	Grade 2 Titanium Socket Head Cap Screws	Material	Titanium Grade 2 (UNS R50400)
Product Form	Cylindrical socket head cap screw	Typical Inquiry Range	M2 to M20 typical inquiry range; UNC, UNF and custom sizes by review
Dimensional References	ISO 4762, DIN 912, ASME B18.3 or approved drawing	Threads / Dimensions	Metric coarse or fine, UNC, UNF or drawing-specific as applicable
Surface	Machined and cleaned; lubricant, anti-galling treatment or coating by agreement	Documents	MTC, heat/lot traceability and dimensional inspection report
Inspection	Dimensions, thread gauging, surface and agreed functional or mechanical tests	Supply Basis	Approved purchase order, invoked standard and drawing

Typical inquiry ranges are not a stock guarantee. Final manufacturability, tolerances and test requirements are confirmed against the complete RFQ.

Selection and Configuration

Socket and tooling: Specify internal-hex size and use matched tooling to protect the drive recess.
Thread engagement: Confirm diameter, pitch, tolerance, threaded length and engagement in the mating component.
Joint compatibility: Review preload, service temperature, mating material, lubrication and galvanic exposure.

Standards and ordering definition: ISO 4762, DIN 912 and ASME B18.3 may define geometry when expressly invoked. Grade 2 material and applicable ASTM F468/F468M requirements must be stated separately.

Send a drawing or complete fastener definition
Include dimensions, quantity, mating parts, service conditions, finish and inspection requirements.

Request a Quotation

Chemical Composition – Titanium Grade 2

Maximum weight percent unless shown otherwise; titanium is the balance.

N max	C max	H max	Fe max	O max	Residual each / total	Ti
0.03	0.08	0.015	0.30	0.25	0.10 / 0.40	Balance

Mechanical Properties – Grade 2 Material Reference

Property	Annealed Grade 2 Material Reference Minimum
Ultimate tensile strength	345 MPa (50 ksi)
0.2% yield strength	275 MPa (40 ksi)
Elongation	20%

Material values do not automatically establish finished-fastener loadability. Finished-part acceptance depends on geometry, manufacturing route, condition and the expressly invoked fastener specification or drawing.

Typical Physical Properties

Property	Typical Value
Density	4.51 g/cm³
Elastic modulus	Approximately 105 GPa
Poisson ratio	Approximately 0.34
Thermal conductivity	Approximately 16.4 W/m·K
Coefficient of thermal expansion	Approximately 8.6 µm/m·K
Melting point	Approximately 1668°C

Physical values are typical engineering references and are not inspection acceptance limits.

Certificates & Inspection Records

SAKY ALLOY quality management system certificate

Services We Can Provide

Drawing ReviewGeometry, thread, tolerances and mating-component review.

Custom ManufacturingMetric, inch and drawing-specific production subject to review.

InspectionDimensional checks, thread gauging and agreed functional testing.

Surface OptionsCleaning, identification, lubricant or coating by agreement.

TraceabilityMTC, heat/lot records and inspection documentation.

Export SupportProtected packing, labeling and shipping documents.

Product Packaging

Grade 2 Titanium Socket Head Cap Screws are separated by size and lot, protected against thread and surface damage, and labeled with grade, dimensions, quantity and traceability reference. Inner bags, cartons and export cases are selected according to product geometry, quantity and shipping method.

Application Scenarios

Chemical Processing

Corrosion-resistant equipment joints selected against the complete process environment.

Power and energy equipment application environment

Power & Energy

Lightweight engineered assemblies requiring controlled dimensions and traceability.

Marine and shipbuilding application environment

Marine & Shipbuilding

Corrosion-resistant joints subject to galvanic, preload and service-condition review.

FAQ

What information is required to quote Grade 2 Titanium Socket Head Cap Screws?

Provide the titanium grade, product form, dimensional standard or drawing, thread or critical dimensions, quantity, surface treatment, mating parts, service conditions and required inspection documents.

Which standards apply to Grade 2 Titanium Socket Head Cap Screws?

ISO 4762, DIN 912 and ASME B18.3 may define geometry when expressly invoked. Grade 2 material and applicable ASTM F468/F468M requirements must be stated separately.

How are Grade 2 Titanium Socket Head Cap Screws inspected?

Available controls include MTC review, head and socket measurement, length checks, GO/NO-GO thread gauging, visual examination and heat/lot traceability.
