ASTM B265 Titanium Plate
Source ASTM B265 titanium plate and sheet in commercially pure and alloy grades, with cut-to-size supply and inspection documents.
- Material
- Commercially pure and alloy grades subject to thickness and order specification
- Standard
- ASTM B265 / ASME SB265
- Supply
- Hot rolled or cold rolled, annealed, pickled, blasted or polished as applicable
- Documents
- MTC, inspection and heat/lot traceability
Product Detail
Product Introduction
Source ASTM B265 titanium plate and sheet in commercially pure and alloy grades, with cut-to-size supply and inspection documents. Final supply is controlled by the grade, specification revision, dimensions, condition, tolerance, inspection and documentation stated on the approved order.
How should an ASTM B265 titanium plate grade be selected?
Selection answer: Choose the grade from the real strength, fabrication, corrosion and application requirements. Grade 2 is a common CP fabrication baseline, Grade 5 is strength-led, Grade 7 is palladium-bearing for corrosion-selected service, and Grade 23 is Ti-6Al-4V ELI under its applicable product specification.
Selection boundary: ASTM B265, ASTM F67, ASTM F136 and AMS flat-product specifications are not interchangeable descriptions. Confirm the product form, UNS, condition, testing, documentation and application controls before substitution.
RFQ data to confirm: Send process medium and temperature or structural duty, grade, specification, dimensions, condition, forming and weld route, inspection, certificate and destination data for RFQ review.
Product Specifications
| Product | ASTM B265 Titanium Plate | Grade | Commercially pure and alloy grades subject to thickness and order specification |
|---|---|---|---|
| Standard | ASTM B265 covers annealed titanium and titanium-alloy strip, sheet and plate across multiple grades. It is not a single alloy designation. A conforming order must identify the ASTM B265 revision, exact grade and UNS where required, product form, thickness, width, length, condition, surface, flatness, edges and supplementary inspection. | Size & Form | Sheet, plate and cut blanks; thickness, width and length are confirmed by RFQ |
| Tolerance | ASTM B265 or customer drawing, including agreed flatness and edge condition | Supply Condition | Hot rolled or cold rolled, annealed, pickled, blasted or polished as applicable |
| Inspection | MTC, chemistry and mechanical results, thickness, dimensions, flatness and surface inspection | Documents | MTC, heat/lot traceability and agreed inspection reports |
Send the complete material RFQ
Include grade, specification revision, dimensions, tolerance, quantity, condition, tests and destination.
Chemical Composition
Weight percent; maximum unless a range is shown. Titanium is the balance. The ordered specification and grade control.
| Grade / UNS | Principal Alloying Elements | Fe max | O max | C max | N max | H max | Ti |
|---|---|---|---|---|---|---|---|
| Grade 1 / R50250 | — | 0.20 | 0.18 | 0.08 | 0.03 | 0.015 | Balance |
| Grade 2 / R50400 | — | 0.30 | 0.25 | 0.08 | 0.03 | 0.015 | Balance |
| Grade 3 / R50550 | — | 0.30 | 0.35 | 0.08 | 0.05 | 0.015 | Balance |
| Grade 4 / R50700 | — | 0.50 | 0.40 | 0.08 | 0.05 | 0.015 | Balance |
| Grade 5 / R56400 | Al 5.50–6.75; V 3.50–4.50 | 0.40 | 0.20 | 0.08 | 0.05 | 0.015 | Balance |
| Grade 6 / R54520 | Al 4.00–6.00; Sn 2.00–3.00 | 0.50 | 0.20 | 0.08 | 0.05 | 0.015 | Balance |
| Grade 7 / R52400 | Pd 0.12–0.25 | 0.30 | 0.25 | 0.08 | 0.03 | 0.015 | Balance |
| Grade 9 / R56320 | Al 2.50–3.50; V 2.00–3.00 | 0.25 | 0.15 | 0.08 | 0.03 | 0.015 | Balance |
| Grade 12 / R53400 | Mo 0.20–0.40; Ni 0.60–0.90 | 0.30 | 0.25 | 0.08 | 0.03 | 0.015 | Balance |
| Grade 11 / R52250 | Pd 0.12–0.25 | 0.20 | 0.18 | 0.08 | 0.03 | 0.0125 | Balance |
| Grade 16 / R52402 | Pd 0.04–0.08 | 0.30 | 0.25 | 0.08 | 0.03 | 0.015 | Balance |
| Grade 17 / R52252 | Pd 0.04–0.08 | 0.20 | 0.18 | 0.08 | 0.03 | 0.0125 | Balance |
| Grade 19 / R58640 | Al 3.00–4.00; V 7.50–8.50; Cr 5.50–6.50; Mo 3.50–4.50; Zr 3.50–4.50 | 0.30 | 0.12 | 0.05 | 0.03 | 0.015 | Balance |
| Grade 23 / R56407 | Al 5.50–6.50; V 3.50–4.50 | 0.25 | 0.13 | 0.08 | 0.05 | 0.0125 | Balance |
Mechanical Properties – Annealed Material Reference
| Grade | Ultimate Tensile Strength min | 0.2% Yield Strength min | Elongation min |
|---|---|---|---|
| Grade 1 | 240 MPa | 170 MPa | 24% |
| Grade 2 | 345 MPa | 275 MPa | 20% |
| Grade 3 | 450 MPa | 380 MPa | 18% |
| Grade 4 | 550 MPa | 483 MPa | 15% |
| Grade 5 | 895 MPa | 828 MPa | 10% |
| Grade 6 | 828 MPa | 793 MPa | 10% |
| Grade 7 | 345 MPa | 275 MPa | 20% |
| Grade 9 | 620 MPa | 485 MPa | 15% |
| Grade 12 | 483 MPa | 345 MPa | 18% |
| Grade 11 | 240 MPa | 170 MPa | 24% |
| Grade 16 | 345 MPa | 275 MPa | 20% |
| Grade 17 | 240 MPa | 170 MPa | 24% |
| Grade 19 / Beta-C | Acceptance depends on solution treatment, aging condition, product form and section size; use the certified values required by the invoked product or aerospace specification. | ||
| Grade 23 | 860 MPa | 795 MPa | 10% |
Representative minima only. Product form, section size, heat treatment and the invoked specification determine the certified acceptance values.
Typical Physical Properties
| Grade | Density | Elastic Modulus | Thermal Expansion |
|---|---|---|---|
| Grade 1 | 4.51 g/cm³ | Approx. 103 GPa | Approx. 8.6 µm/m·K |
| Grade 2 | 4.51 g/cm³ | Approx. 105 GPa | Approx. 8.6 µm/m·K |
| Grade 3 | 4.51 g/cm³ | Approx. 105 GPa | Approx. 8.6 µm/m·K |
| Grade 4 | 4.51 g/cm³ | Approx. 105 GPa | Approx. 8.6 µm/m·K |
| Grade 5 | 4.43 g/cm³ | Approx. 114 GPa | Approx. 8.6 µm/m·K |
| Grade 6 | Approx. 4.48 g/cm³ | Approx. 110 GPa | Approx. 8.8 µm/m·K |
| Grade 7 | Approx. 4.51 g/cm³ | Approx. 105 GPa | Approx. 8.6 µm/m·K |
| Grade 9 | Approx. 4.48 g/cm³ | Approx. 105 GPa | Approx. 9.0 µm/m·K |
| Grade 12 | Approx. 4.54 g/cm³ | Approx. 103 GPa | Approx. 8.6 µm/m·K |
| Grade 11 | Approx. 4.51 g/cm³ | Approx. 103 GPa | Approx. 8.6 µm/m·K |
| Grade 16 | Approx. 4.51 g/cm³ | Approx. 105 GPa | Approx. 8.6 µm/m·K |
| Grade 17 | Approx. 4.51 g/cm³ | Approx. 103 GPa | Approx. 8.6 µm/m·K |
| Grade 19 / Beta-C | Approx. 4.82 g/cm³ | Condition-dependent; use certified engineering data | Condition-dependent; verify for design |
| Grade 23 | 4.43 g/cm³ | Approx. 114 GPa | Approx. 8.6 µm/m·K |
Typical engineering references, not inspection acceptance limits.
Certificates & Inspection Records
Services We Can Provide
Product Packaging
Sheet and plate surfaces are interleaved or wrapped as required, protected at edges and secured on pallets or in export cases with grade, heat and dimensional identification. Typical export packaging for the same physical product form is shown below; final packing is confirmed for each order.
Application Scenarios
Chemical process equipment
Material grade, dimensions, condition and inspection must be matched to the application requirements.
Aerospace fabrication
Material grade, dimensions, condition and inspection must be matched to the application requirements.
Marine and desalination systems
Material grade, dimensions, condition and inspection must be matched to the application requirements.
FAQ
Does ASTM B265 define one titanium plate grade?
No. ASTM B265 covers multiple commercially pure and alloyed titanium grades. The purchase order must state the exact grade, such as Grade 2, Grade 5, Grade 7 or Grade 23, plus the required product form and dimensions.
How should sheet and plate be distinguished on an ASTM B265 order?
Name strip, sheet, plate or cut blank explicitly and provide thickness, width, length, flatness, surface, edges and tolerance requirements. An informal thickness label does not replace the product-form and dimensional requirements of the standard.
What information is needed to quote ASTM B265 titanium plate?
Provide the ASTM B265 revision, grade and UNS, plate, sheet or cut-blank form, thickness, width, length, quantity, condition, surface, flatness, edge, application, fabrication route, NDT, MTC, marking and heat traceability.
