Grade 2 Titanium Low Head Socket Cap Screws
Grade 2 Titanium Low Head Socket Cap Screws with shallow cylindrical heads for corrosion-resistant assemblies where vertical clearance is limited. Head, socket, thread and inspection follow the approved order.
- Material
- Grade 2 / UNS R50400
- Head
- Low cylindrical socket head
- Drive
- Internal hex socket
- Documents
- MTC, dimensions and thread inspection
Product Detail
Product Introduction
Grade 2 Titanium Low Head Socket Cap Screws reduce head height while retaining an internal-hex drive. The lower head changes socket depth, head strength and allowable installation torque compared with a standard socket head cap screw, so substitution requires verification of clamp load, clearance, bearing stress, thread engagement and service loading.
Product Specifications
| Product | Grade 2 Titanium Low Head Socket Cap Screws | Material | Titanium Grade 2 / UNS R50400 |
|---|---|---|---|
| Product Form | Standard or drawing-specific titanium fastener | Typical Inquiry Range | Metric, inch and custom sizes confirmed at RFQ stage |
| Dimensional References | Expressly invoked standard or approved drawing | Threads / Dimensions | Metric coarse or fine, UNC, UNF or drawing-specific as applicable |
| Surface | Machined and cleaned; lubricant, anti-galling treatment or coating by agreement | Documents | MTC, heat/lot traceability and dimensional inspection report |
| Inspection | Dimensions, thread gauging, surface and agreed functional or mechanical tests | Supply Basis | Approved purchase order, invoked standard and drawing |
Typical inquiry ranges are not a stock guarantee. Final manufacturability, tolerances and test requirements are confirmed against the complete RFQ.
Selection and Configuration
- Height restriction: Define maximum head projection, counterbore or surrounding clearance and required bearing-face diameter.
- Drive and torque: Confirm socket size, engagement, tightening tool and permitted torque for the selected shallow-head geometry.
- Threaded joint: State thread, tolerance, length, engagement, mating material, preload method, lubrication and reuse expectations.
Send a drawing or complete fastener definition
Include dimensions, quantity, mating parts, service conditions, finish and inspection requirements.
Chemical Composition – Titanium Grade 2
Maximum weight percent unless shown otherwise; titanium is the balance.
| N max | C max | H max | Fe max | O max | Residual each / total | Ti |
|---|---|---|---|---|---|---|
| 0.03 | 0.08 | 0.015 | 0.30 | 0.25 | 0.10 / 0.40 | Balance |
Mechanical Properties – Grade 2 Material Reference
| Property | Annealed Grade 2 Material Reference Minimum |
|---|---|
| Ultimate tensile strength | 345 MPa (50 ksi) |
| 0.2% yield strength | 275 MPa (40 ksi) |
| Elongation | 20% |
Material values do not automatically establish finished-fastener loadability. Finished-part acceptance depends on geometry, manufacturing route, condition and the expressly invoked fastener specification or drawing.
Typical Physical Properties
| Property | Typical Value |
|---|---|
| Density | 4.51 g/cm³ |
| Elastic modulus | Approximately 105 GPa |
| Poisson ratio | Approximately 0.34 |
| Thermal conductivity | Approximately 16.4 W/m·K |
| Coefficient of thermal expansion | Approximately 8.6 µm/m·K |
| Melting point | Approximately 1668°C |
Physical values are typical engineering references and are not inspection acceptance limits.
Certificates & Inspection Records
Services We Can Provide
Product Packaging
Grade 2 Titanium Low Head Socket Cap Screws are separated by size and lot, protected against thread and surface damage, and labeled with grade, dimensions, quantity and traceability reference. Inner bags, cartons and export cases are selected according to product geometry, quantity and shipping method.
Application Scenarios
Chemical Processing
Corrosion-resistant equipment joints selected against the complete process environment.
Power & Energy
Lightweight engineered assemblies requiring controlled dimensions and traceability.
Marine & Shipbuilding
Corrosion-resistant joints subject to galvanic, preload and service-condition review.
FAQ
How is a low head screw different from a standard socket head cap screw?
It has a shallower cylindrical head and usually reduced socket engagement. Clearance improves, but head capacity and tightening limits must be reviewed.
Can DIN 7984 steel torque values be used directly for titanium?
No. Installation torque depends on titanium grade, finished-part requirements, thread friction, lubrication, mating material and joint validation.
What dimensions should be inspected?
Head height and diameter, socket dimensions, overall length, thread size and fit, bearing face and any drawing-specific concentricity requirements should be defined.
