Grade 2 Titanium Button Head Socket Screws

Grade 2 Titanium Button Head Socket Screws

Grade 2 Titanium Button Head Socket Screws with low rounded heads and internal hex drives for corrosion-resistant assemblies requiring a broad bearing face and reduced head profile.

Material
Grade 2 / UNS R50400
Head
Rounded button head
Drive
Internal hex socket
Documents
MTC, dimensions and thread inspection
CONTACT US

Product Detail

Product Introduction

Grade 2 Titanium Button Head Socket Screws combine an internal-hex drive with a low rounded head and broad underside bearing surface. Selection must account for available wrenching depth, permitted head projection, bearing stress, required clamp load, thread engagement, mating material, tightening method and galling control.

Product Specifications

ProductGrade 2 Titanium Button Head Socket ScrewsMaterialTitanium Grade 2 / UNS R50400
Product FormStandard or drawing-specific titanium fastenerTypical Inquiry RangeMetric, inch and custom sizes confirmed at RFQ stage
Dimensional ReferencesExpressly invoked standard or approved drawingThreads / DimensionsMetric coarse or fine, UNC, UNF or drawing-specific as applicable
SurfaceMachined and cleaned; lubricant, anti-galling treatment or coating by agreementDocumentsMTC, heat/lot traceability and dimensional inspection report
InspectionDimensions, thread gauging, surface and agreed functional or mechanical testsSupply BasisApproved purchase order, invoked standard and drawing

Typical inquiry ranges are not a stock guarantee. Final manufacturability, tolerances and test requirements are confirmed against the complete RFQ.

Selection and Configuration

  • Head envelope: Define head diameter, height, bearing face and clearance around the rounded profile.
  • Drive capacity: Confirm socket size, key engagement and installation torque because the shallow head provides less drive depth than many standard socket heads.
  • Joint definition: Specify thread, fit, length, grip, engagement, mating material, washer use, preload method and service environment.
Standards and ordering definition: ISO 7380-1 or an expressly invoked ASME B18.3 geometry may be reviewed. The order must separately define titanium grade, condition, finished-screw acceptance, mechanical requirements, surface condition, testing and documentation.

Send a drawing or complete fastener definition
Include dimensions, quantity, mating parts, service conditions, finish and inspection requirements.

Request a Quotation

Chemical Composition – Titanium Grade 2

Maximum weight percent unless shown otherwise; titanium is the balance.

N maxC maxH maxFe maxO maxResidual each / totalTi
0.030.080.0150.300.250.10 / 0.40Balance

Mechanical Properties – Grade 2 Material Reference

PropertyAnnealed Grade 2 Material Reference Minimum
Ultimate tensile strength345 MPa (50 ksi)
0.2% yield strength275 MPa (40 ksi)
Elongation20%

Material values do not automatically establish finished-fastener loadability. Finished-part acceptance depends on geometry, manufacturing route, condition and the expressly invoked fastener specification or drawing.

Typical Physical Properties

PropertyTypical Value
Density4.51 g/cm³
Elastic modulusApproximately 105 GPa
Poisson ratioApproximately 0.34
Thermal conductivityApproximately 16.4 W/m·K
Coefficient of thermal expansionApproximately 8.6 µm/m·K
Melting pointApproximately 1668°C

Physical values are typical engineering references and are not inspection acceptance limits.

Certificates & Inspection Records

SAKY ALLOY quality management system certificate

Services We Can Provide

Drawing ReviewGeometry, thread, tolerances and mating-component review.
Custom ManufacturingMetric, inch and drawing-specific production subject to review.
InspectionDimensional checks, thread gauging and agreed functional testing.
Surface OptionsCleaning, identification, lubricant or coating by agreement.
TraceabilityMTC, heat/lot records and inspection documentation.
Export SupportProtected packing, labeling and shipping documents.

Product Packaging

Grade 2 Titanium Button Head Socket Screws are separated by size and lot, protected against thread and surface damage, and labeled with grade, dimensions, quantity and traceability reference. Inner bags, cartons and export cases are selected according to product geometry, quantity and shipping method.

Application Scenarios

Chemical processing equipment application environment

Chemical Processing

Corrosion-resistant equipment joints selected against the complete process environment.

Power and energy equipment application environment

Power & Energy

Lightweight engineered assemblies requiring controlled dimensions and traceability.

Marine and shipbuilding application environment

Marine & Shipbuilding

Corrosion-resistant joints subject to galvanic, preload and service-condition review.

FAQ

Why select a button head socket screw?

It provides a smooth low rounded profile and broad bearing face where a standard cylindrical socket head is too tall. Available drive depth and permitted tightening torque must still be checked.

Does ISO 7380-1 define the titanium material?

No. It can define geometry when invoked, while titanium grade, condition, mechanical acceptance, finish, tests and certificates must be specified separately.

Can a button head screw replace a standard socket head cap screw?

Not automatically. Head strength, socket depth, installation torque, bearing area, clamp load and clearance differ and require joint review.
